MENTOR 12
MENTOR 12 TECHNICAL SPECIFICATIONS
POWER OUTPUT
GENERAL
Dimensions 422 x 254 x 511 mm. / 16.6” x 10” x 20.1”
Weight 22.5 kg. / 49.6 lb(6 ch.) – 29.8 Kg /65.6 lb (12 ch.)
Casing Custom
Consumption Max. 1600 VA. 100 - 260 V AC, 40 – 70 Hz
Compliance/CE Marking IEC-61010 / EMC-50081-2 / EN-50082-2
Working Temperature 0º to 50º C // 32º F to 122º F
Storage temperature -40º to +70º C // -40º F to 158º F
Humidity Up to 95% (non condensating)
Display Color TFT 800 x 600
Control Touch panel + rotary encoder
Communications RS-232, 2 x USB, Ethernet, Centronics, PS2, VGA
LOW LEVEL OUTPUTS
NUMBER TYPE LEVELS RANGES ISOLATION RESOLUTION ACCURACY DISTORTION
6 V 0-10 Vpk (1 mA max.) 1 No 250 µV 0.07 % 0.05 %
TIMERS
NUMBER RESOLUTION RANGES ACCURACY
4 0.1 ms 00000.0001 – 99999.9999 sec. 0.001 % +/- 0.1 ms
BINARY INPUTS
NUMBER TYPE THRESHOLDS RANGES ISOLATION RESOLUTION COUNTER FUNCTION
12 Dry or voltage 1.5, 15 V +/-400 V (p-p) 6 groups of 2 0.1 ms Up to 3 kHz. (width: 150 µs) 100 kHz. in 1 group
BINARY OUTPUTS
NUMBER TYPE LEVELS ISOLATION TIME RESOLUTION
8 Relay or Open Collector 300 Vdc / 300 Vac / 8 A 2000 VA / 240 W Yes 100 µs
AUXILIARY DC SUPPLY
RANGES POWER ACCURACY RIPPLE
48, 125, 250 Vdc 60 W 5 % 0.2 %
EXT. MEASUREMENT
Vdc MEASUREMENT INPUT Idc MEASUREMENT INPUT ACCURACY
± 10 V ± 20 mA 0.02 %
Please note: Due to the continuous research and de
velopment b
y EuroSMC,
specifications in this catalog ma
y be chang
ed without
pre
vious notice.
JA
A
CCEN -
V ersion 3
VOLTAGE AMPLIFIERS CURRENT AMPLIFIERS
Capacity 1 - 6 1 - 6
Output ranges per channel 0 - 150 V AC / 0 - 5 A AC / 0 - 212 V DC / 0 - 5 A DC 0 - 25 A AC and DC
Outputs configurations
Up to 6 x (150 V AC 100 VA / 212 DC)
Up to 3 x (300 V AC 200 VA / 424 DC)
Up to 1 x (600 V AC 400 VA / 848 DC) +1 x (300 V AC 200 VA / 424 DC)
As current mode:
Up to 6 x (5 A AC 100 VA / 5 DC)
Up to 3 x (10 A AC 200 VA / 10 DC)
Up to 1 x (20 A AC 400 VA / 20 DC) + 2 x (5 A AC 100 VA / 5 DC)
Up to 6 x (25 A AC 100 VA / 25 DC)
Up to 3 x (50 A AC 200 VA / 50 DC)
Up to 1 x (100 A AC 400 VA / 100 DC) + 1 x (50 A AC 200 VA / 50 DC)
Up to 1 x (150 A AC 600 VA / 150 DC)
Power per channel 100 VA continuous @ 37.5 – 150 V AC, 100W 100 VA @ 9.5 A AC, 100 W
Adjustment resolution 5 mV / 0.5 mA 0.5 mA
Reversibility Yes No
Accuracy 0.1% of the value ± 0.03% of the range (20-30º) @ 50-60 Hz
Distortion 0.1 % @ 50-60 Hz (resistive load) / 2 % @ 50-60 Hz (maximum inductive load)
Isolation Yes (from mains and between all channels)
Combined output Series and Parallel
Frequency Adjustment range: 0.0 – 2000 Hz / Bandwidth: 3000 Hz / Resolution: 5 µHz / Accuracy: 1 ppm
Phase angle Range: 0.0 – 359.9º /Accuracy: 0.1º / Resolution: 0.001º
