Optional Accessories
Technical data
P/N: 62101-0301
Spatial resolution (IFOV) Depends on the IR resolution of the camera: © 2013, FLIR Systems, Inc.
5.18 mrad for 160 × 120 pixels All rights reserved worldwide.
4.14 mrad for 200 × 150 pixels
3.45 mrad for 240 × 180 pixels
2.59 mrad for 320 × 240 pixels
F-number 1.3
Weight 0.105 kg (0.231 lb.), incl. two lens caps
Size (L × D) 38 × 47 mm (1.5 × 1.9 in.)
Shipping information
• Lens
• Lens case
v1.03
T197215; Close-up 4× (100 µm) incl. case
General description
For R&D usage or development purposes. As an example looking at PCB's or small electronic components.
Technical data
Field of view (FOV) 32 × 24 mm
Magnifying factor 4×
Working distance 79 mm
Depth of field ±2.0 mm
Focal length 73 mm (2.9 in.)
Spatial resolution (IFOV) Depends on the IR resolution of the camera:
200 µm for 160 × 120 pixels
160 µm for 200 × 150 pixels
133 µm for 240 × 180 pixels
100 µm for 320 × 240 pixels
F-number 1.3
Number of lenses 2 (2 asph)
MTF @ 70% of FOV Normal requirements (52%)
Distortion 3%
Weight 0.11 kg (0.24 lb.)
Size (L × D) 35.2 × 55 mm
Shipping information
• Lens
• Lens case
v1.03
