Atec Flir-T440-wifi User Manual
Technical data

Technical Data
FLIR T440 25° (incl. Wi-Fi)
Part number:
62101-0301
Copyright
© 2013, FLIR Systems, Inc.
All rights reserved worldwide. Names and marks
appearing herein are either registered trademarks or
trademarks of FLIR Systems and/or its subsidiaries. All
other trademarks, trade names or company names
referenced herein are used for identification only and
are the property of their respective owners.
July 10, 2013, 04:11 AM
Corporate Headquarters
FLIR Systems, Inc.
27700 SW Parkway Ave.
Wilsonville, OR 97070
USA
Telephone: +1-503-498-3547
General description
Website
http://www.flir.com
The FLIR T440 is a camera that offers good performance at an affordable price. Excellent ergonomics and easy
communication makes the T440 a truly user-friendly camera for the beginner or advanced user.
Customer support
Benefits:
http://support.flir.com
•
Excellent ergonomics: The T440 has a tiltable IR unit, which makes it easy to capture images from any angle
Legal disclaimer
comfortably. The size and low weight of the camera facilitates its use over a full working day.
Specifications subject to change without further notice.
•
Affordable performance: The T440 camera is equipped with the innovative ‘Multi Spectral Dynamic Imaging (MSX)’
Camera models and accessories subject to regional
feature, which produces an image more rich in detail than ever before. You can highlight objects of interest, both on
market considerations. License procedures may apply.
the IR and the visual image, by sketching directly on the camera’s touch screen.
•
Extensive communication possibilities: The Wi-Fi connectivity of the T440 allows you to connect to smart phones or
Information and equipment described herein may
tablet PCs, for the wireless transfer of images or remote control of the camera. The Bluetooth®-based Meterlink™
require US Government authorization for export
function transfers readings from external measurement instruments to the IR image.
purposes. Diversion contrary to US law is prohibited.
Imaging and optical data
IR resolution
320 × 240 pixels
Thermal sensitivity/NETD
< 45 mK @ +30°C (+86°F)
Field of view (FOV)
25° × 19°
Minimum focus distance
0.4 m (1.31 ft.)
Focal length
18 mm (0.7 in.)
Spatial resolution (IFOV)
1.39 mrad
F-number
1.3
Image frequency
60 Hz
Focus
Automatic (one shot) or manual
Digital zoom
2Ч, 4Ч and 8×
Detector data
Detector type
Focal plane array (FPA), uncooled microbolometer
Spectral range
7.5–13 µm
Image presentation
Display
Touch screen, 3.5 in. LCD, 320 × 240 pixels
Image adjustment
Auto or manual
Image presentation modes
Image modes
IR image, visual image, thermal fusion, picture in picture,
thumbnail gallery
Thermal fusion
IR image shown above, below or within temp interval on
visual image
Multi Spectral Dynamic Imaging (MSX)
IR-image with enhanced detail presentation
Picture in Picture
Resizable and movable IR area on visual image
Page 1 (of 47)
http://www.flir.com
62101-0301_en_41.xml,
ver.
1.12
Document Outline
- Technical data
- Optional Accessories
- 1196961; IR lens, f = 30 mm, 15° incl. case
- 1196960; IR lens, f = 10 mm, 45° incl. case
- T197215; Close-up 4× (100 µm) incl. case
- T197214; Close-up 2× (50 µm) incl. case
- T197408; IR lens, 76 mm (6°) with case and mounting support for T/B-200/400
- T197412; IR lens, 4 mm (90°) with case and mounting support for T/B2xx-4xx
- 1196398; Battery
- T197667; Battery package
- T197650; 2-bay battery charger, incl. power supply with multi plugs
- T910750; Power supply, incl. multi plugs
- T911173; Memory card SD
- 1910423; USB cable Std A <-> Mini-B
- 1910490; Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft.
- 1910582; Video cable
- T198370; Hard transport case for FLIR T/B2xx-4xx
- T911048; Pouch for FLIR T6xx and T4xx series
- 1124544; Neck strap
- 1123970; Sun shield
- T197771; Bluetooth Headset
- T198598; Value pack T4xx 2013-01
- T910972; EX845: Clamp meter + IR therm TRMS 1000A AC/DC
- T910973; MO297: Moisture meter, pinless with memory
- T911093; Tool belt
- 19250-100; IR Window 2 in
- 19251-100; IR Window 3 in.
- 19252-100; IR Window 4 in.
- Optional Software
- T197717; FLIR Reporter Professional (DVD)
- T127451; FLIR Reporter Professional (license only)
- T197965; FLIR Tools
- T127648; FLIR Tools+ (license only)
- DSW-10000; FLIR IR Camera Player
- APP-10002; FLIR Tools Mobile (Android Application)
- APP-10003; FLIR Tools Mobile (iPad/iPhone Application)
- T198206; FLIR ResearchIR 3 (CD)
- T127597; FLIR ResearchIR 3 (license only)
- T127597L5; FLIR ResearchIR 3 (license only), 5 user licenses
- T127597L10; FLIR ResearchIR 3 (license only), 10 user licenses
- T198209; FLIR ResearchIR 3 Max (CD)
- T127598; FLIR ResearchIR 3 Max (license only)
- T127598L5; FLIR ResearchIR 3 Max (license only), 5 user licenses
- T127598L10; FLIR ResearchIR 3 Max (license only), 10 user licenses
- T198292; Upgrade previous version to FLIR ResearchIR 3
- T198291; Upgrade previous version to FLIR ResearchIR 3 Max
- T198290; Upgrade FLIR ResearchIR 3 to FLIR ResearchIR 3 Max
- Mechanical drawings
