4,27in
108,5mm
5,06in
128,5mm
1,22in 31mm
3,48in
88,5mm
Lens support
optional
8,02in
203,7mm
0,55in 14mm
3,78in 96mm
0,51in 13mm
4,17in
105,8mm
Camera with Lens IR f=76 mm (6°) incl support
Sheet
Drawing No.
Size
Check Drawn by
Denomination A3
5(7)
T127604
Basic Dimensions FLIR T4xx
JOTA 2012-06-07 R&D Thermography
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 3 2 5 4
C
F
B
D
G
E
A
6
Size
A
1:2
Scale
