2,28in
58mm
1,22in 31mm
1,85in 47mm
4,81in
122,1mm
0,95in 24,3mm
Camera with Lens IR f=30 mm (15°)
Sheet
Drawing No.
Size
Check Drawn by
Denomination A3
4(7)
T127604
Basic Dimensions FLIR T4xx
JOTA 2012-06-07 R&D Thermography
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 3 2 5 4
C
F
B
D
G
E
A
6
Size
A
1:2
Scale
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise, without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply. Product may be subject to US Export Regulations. Please refer to [email protected] with any questions. Diversion contrary to US law is prohibited.
-
