Optional Accessories
P/N: 62101-0301
T910972; EX845: Clamp meter + IR therm TRMS
© 2013, FLIR Systems, Inc. 1000A AC/DC
All rights reserved worldwide.
General description
Bluetooth Transmitter with METERLiNK™
Wirelessly transmits Voltage and Current readings to your FLIR high-definition infrared camera to incorporate meter
readings with thermal images.
For more info see www.extech.com
METERLiNK™ makes it easy for a thermographer to quickly take electrical readings using an Extech EX845 clamp
meter and instantly record them right on an infrared image. METERLiNK™ accelerates infrared inspections and
diagnostics while adding value to your reports by increasing the amount of detail you provide.
EX845 CAT IV Clamp Meter Features:
• Patented built-in non-contact IR Thermometer design with laser pointer
• True RMS Current and Voltage measurements
• Peak hold captures inrush currents and Transients
• MultiMeter functions include AC/DC Voltage, Resistance, Capacitance, Frequency, Diode, and Continuity
• 1.7" (43mm) jaw opening for conductors up to 750MCM or two 500MCM
• 4000 count backlit display
• Features include Data Hold and Min/Max and Auto Power off
• Autoranging with manual range button
• Complete with CAT IV test leads, 9V battery, Type K probe (-22 to 572°F/-30 to 300°C), pouch case, and
Professional Test Lead Set
Professional Test Lead Features:
• 8-Piece Professional Test Lead set
• Two 42" (1m) PVC lead extensions with shrouded banana plugs at both ends
• Two modular 4" (102mm) Heavy Duty test probe handles with 0.16" (4mm) banana plug tip
• Two standard size, alligator clips with insulated rubber boot
• Two extra large, double-insulated, alligator clips with sharp teeth for piercing insulated wire. Jaws open to 0.8"
(20mm)
