1,85in
47mm
2,41in 61,1mm
1,22in 31mm
5,37in
136,3mm
1,51in 38,4mm
Camera with Lens IR f=10 mm (45°)
Sheet
Drawing No.
Size
Check Drawn by
Denomination A3
3(7)
T127604
Basic Dimensions FLIR T4xx
JOTA 2012-06-07 R&D Thermography
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 3 2 5 4
C
F
B
D
G
E
A
6
Size
A
1:2
Scale
