Atec Flir-T440-wifi - Manual (Page 52)

2,17in
55mm
2,28in 57,9mm
1,22in 31mm
5,27in
134mm
1,39in 35,2mm
Camera with Close-up lens 2X (50 µm)
Sheet
Drawing No.
Size
Check Drawn by
Denomination A3
6(7)
T127604
Basic Dimensions FLIR T4xx
JOTA 2012-06-07 R&D Thermography
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 3 2 5 4
C
F
B
D
G
E
A
6
Size
A
1:2
Scale
