Optional Accessories

P/N: 62101-0301

1196961; IR lens, f = 30 mm, 15° incl. case

General description

The 15° lens is a popular lens accessory and provides 1.7× magnification compared to the standard lens. Ideal for small
or distant targets such as overhead power lines.

Technical data

Field of view (FOV)

15° × 11.25°

Minimum focus distance

1.2 m (3.93 ft.)

Focal length

30.38 mm (1.2 in.)

Spatial resolution (IFOV)

Depends on the IR resolution of the camera:
1.65 mrad for 160 × 120 pixels
1.32 mrad for 200 × 150 pixels
1.10 mrad for 240 × 180 pixels
0.82 mrad for 320 × 240 pixels

F-number

1.3

Weight

0.092 kg (0.203 lb.), incl. two lens caps

Size (L × D)

24 × 58 mm (1.0 × 2.3 in.)

Shipping information

•

Lens

•

Lens case

v1.04

1196960; IR lens, f = 10 mm, 45° incl. case

General description

This wide angle lens has a field of view almost double that of the standard lens. Perfect for wide or tall targets or when
working in crowded spaces.

Technical data

Field of view (FOV)

45° × 33.8°

Minimum focus distance

0.20 m (0.66 ft.)

Focal length

9.66 mm (0.38 in.)
