Version 03.00, August 2011
22 Rohde & Schwarz R&S ® UPV Audio Analyzer
Graphical display of results
Monitor (not R&S
® UPV66) 8.4" LCD, color
numeric display
combi display with numeric value,
bargraph, min./max. and limits
(for each numeric result)
sweep trace
spectrum
waveform
list of results
Display of results
bargraph for THD and intermodulation
measurements
autoscale
X- and Y-axis zoom
2 vertical and 2 horizontal cursor lines
search function for max. values
marker for harmonics (spectrum)
Display functions
change of unit and scale also possible for
loaded traces
Test reports
Functions
screen copy to clipboard, file or printer
Audio monitor
Loudspeaker built in
Headphone connector 6.3 mm jack
Output voltage peak max. 7 V
Source impedance 100 Ω, short-circuit-proof
Recommended headphone impedance 600 Ω
150 Ω modification (R&S
®
UPV-U1 option)
Change of source impedance of analog generator to 150 Ω (instead of factory-set value of 200 Ω ).
BNC phone out (R&S
®
UPV-U2 option)
Two BNC connectors at the rear panel in parallel to the left and right channels of the headphone output.
Digital audio protocol (R&S
®
UPV-K21 option)
Digital audio I/O 192 kHz (R&S ® UPV-B2 option) required.
Generator
Validity bit
NONE, L+R
Channel status data mnemonic entry for professional and
consumer format in line with AES3 or
IEC 60958
Analyzer
Error flags
PCM, parity, lock, CRC, validity
Channel status display binary and mnemonic display of data fields
in line with AES3 or IEC 60958
