4
Frequency Specifications
Frequency range
Frequency range Option 503 9 kHz (5 MHz IQ mode) to 3 GHz
Option 506 9 kHz (5 MHz IQ mode) to 6 GHz
Resolution 0 .01 Hz
Phase offset Adjustable in nominal 0 .1 ° increments
Frequency bands 1
Band Frequency range N
1 9 kHz to < 5 MHz 1 (digital synthesis)
1 5 to < 250 MHz 1
2 250 to < 375 MHz 0 .25
3 375 to < 750 MHz 0 .5
4 750 to < 1500 MHz 1
5 1500 to < 3000 .001 MHz 2
6 3000 .001 to 6000 MHz 4
1. N is a factor used to help define certain specifications within the document.
Frequency switching speed 1, 2
Standard Option UNZ 3
Option UNZ, typical
CW mode
SCPI mode
≤ 5 ms, typical ≤ 1 .15 ms ≤ 950 µs
List/step sweep mode ≤ 5 ms, typical ≤ 900 µs ≤ 800 µs
Digital modulation on (N5182B only)
SCPI mode
≤ 5 ms, typical ≤ 1 .15 ms ≤ 1 .05 ms
List/step sweep mode ≤ 5 ms, typical ≤ 900 µs ≤ 800 µs
1. Time from receipt of SCPI command or trigger signal to within 0.1 ppm of final frequency or within 100 Hz, whichever is greater, and amplitude
settled to within 0.2 dB from 20 to 30 °C. When switching into or out of band 6 amplitude settling time is within 0.3 dB. Implies simultaneous
frequency and amplitude switching.
2. With internal channel corrections on, the frequency switching speed is < 1.3 ms, measured for list mode and SCPI mode cached frequency points.
For the initial frequency point in SCPI mode the time is < 3.3 ms, measured. The instrument will automatically cache the most recently used 1024
frequencies. There is no speed degradation for amplitude-only changes.
3. Specifications apply when status register updates are off.
