Table of Contents
Definitions and conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Frequency specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Amplitude specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Spectral purity specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Analog modulation specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Vector modulation specifications - N5182B only . . . . . . . . . . . . . . . . . . . . . . . . . .18
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Inputs and outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Related literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Pure and precise
On the path to better performance,
the new MXG X-Series signal
generators are fine-tuned to be
your “golden transmitter” in R&D .
Whether you’re pushing for a
linear RF chain or an optimized
link budget, the analog and vector
MXG models deliver what you
need: phase noise, ACPR, channel
coding, and more . Take your
devices and designs to the limit
with the MXG .
