Arbitrary waveform memory
Maximum playback
capacity
32 Msa (standard)
512 Msa (Option 022)
1024 Msa (Option 023)
Maximum storage
capacity including
markers
3 GBytes/800 Msa (standard)
30 GBytes/7 .5 Gsa (Option 009)
8 GBytes / 2 Gsa (Option 006)
Waveform segments
Segment length
60 samples to 32 Msa (standard)
60 samples to 512 Msa (Option 022)
60 samples to 1024 Msa (Option 023)
Minimum memory
allocation per
segment
256 samples
Maximum number of
segments
8192
Waveform sequences Maximum number of
sequences
> 2000 depending on non-volatile memory usage
Maximum number of
segments/sequence
32,000 (standard)
4 million (Option 022 or 023)
Maximum number of
repetitions
65,535
Triggers Types Continuous, single, gated, segment advance
Source Trigger key, external, bus (GPIB, LAN, USB)
Modes
Continuous Free run, trigger and run, reset and run
Single No retrigger, buffered trigger, restart on trigger
Gated Negative polarity or positive polarity
Segment advance Single or continuous
External coarse delay time 5 ns to 40 s
External coarse delay resolution 5 ns
Trigger latency (Single trigger only) 356 ns + 1 sample clock period, nominal
Trigger accuracy (Single trigger only) ± 2 .5 ns, nominal
Single trigger - restart on trigger mode will initiate a FIFO clear . Therefore, the latency includes
re-filling the buffer . The latency is 8 µs + (1406 x sample period) ± 1 sample clock period, nominal
Multi-baseband generator
synchronization mode
(multiple sources)
Fan out 1 master and up to 15 slaves
Trigger repeatability < 1 ns, nominal
Trigger accuracy Same as normal mode
Trigger latency Same as normal mode
Fine trigger delay range See Internal IQ Baseband section
Fine trigger delay resolution See Internal IQ Baseband section
IQ phase adjustment range See Internal IQ Baseband section
