19
Internal real-time complex digital I/Q filters (included with Option 656)
Factory channel correction (256 taps)
Corrects the linear phase and amplitude response of the baseband IQ and RF outputs of the signal generator using factory calibration
arrays . (default mode is off)
RF amplitude flatness (160 MHz)
± 0 .2 dB measured
RF phase flatness (160 MHz) ± 2 degrees measured
User channel correction (256 taps)
Automated routine uses power sensor to correct for linear phase and amplitude response of DUT (equalizer) . See Users Guide for
more details .
Recommended max amplitude error for
correction
± 15 dB
Recommended max phase error for
correction
± 25 degrees
Equalization filter (256 taps)
User can download and apply inverse or custom phase and amplitude response coefficients from tools such as MATLAB, 89600 VSA
or SystemVue to correct for linear errors of DUT/system . See Users Guide for more details .
Baseband generator (Options 656 and 657)
Channels 2 [I and Q]
Resolution 16 bits [1/65,536]
Sample rate Option 656
Option 656 and 657
100 Sa/s to 100 MSa/s
100 Sa/s to 200 MSa/s
RF (I+Q) bandwidth Option 656
Option 656 and 657
80 MHz, nominal
160 MHz, nominal
Interpolated DAC rate 800 MHz (waveforms only need OSR = 1 .25 )
Frequency offset range ± 80 MHz
Digital sweep modes In list sweep mode each point in the list can have independent waveforms (N5182B)
along with user definable frequencies and amplitudes; see the Amplitude and Frequency
Specifications sections for more detail .
Waveform switching speed 1
SCPI mode
≤ 5 ms, measured (standard)
≤ 1 .2 ms, measured (Option UNZ)
List/step sweep mode
≤ 5 ms, measured (standard)
≤ 900 us, measured (Option UNZ)
Waveform transfer rates
(measured, no markers)
FTP LAN to internal SSD 10 .7 MB/sec or 2 .67 Msa/sec
Internal SSD to FTP LAN 7 .7 MB/sec 1 .92 Msa/sec
FTP LAN to BBG 8 .2 MB/sec or 2 .05 Msa/sec
FTP LAN to BBG encrypted 4 MB/sec or 1 Msa/sec
USB to BBG 19 MB/sec or 4 .75 Msa/sec
BBG to USB 1 .2 MB/sec or 300 Ksa/sec
Internal SSD to BBG 48 MB/sec or 12 Msa/sec
BBG to internal SSD 1 .2 MB/sec or 300 Ksa/sec
SD card to BBG (Option 006) 2 .7 MB/sec or 678 Ksa/sec
BBG to SD card (Option 006) 845 KB/sec or 211 Ksa/sec
1. SCPI mode switching speed applies when waveforms are pre-loaded in list sweep and sample rate ≥ 10 MSa/s.
