N8480 Series Thermocouple Power Sensor Specifications
The N8480 Series power sensors (excluding Option CFT) measure power levels
from –35 dBm to +44 dBm (316 nW to 25.1 W), at frequencies from 100 kHz to
50 GHz and have two independent power measurement range (upper and lower
range).
Meanwhile, the N8480 sensors with Option CFT only measure power levels
from –30 dBm to +44 dBm (1 μW to 25.1 W) in single range. Similiar to the
E-Series power sensors, the N8480 Series power sensors are also equipped with
EEPROM to store sensor’s characteristics such as model number, serial number,
linearity, temperature compensation, calibration factor, and so forth.
This feature ensures the correct calibration data is applied by any compatible
power meter connected with N8480 Series power sensor, and to ensure the
accuracy of the measurements.
Calibration factor uncertainties
Table 15. N8480 Series calibration factor uncertainty at 25 ºC ± 3 ºC
Frequency N8481A N8481B N8481H N8482A N8482B N8482H N8485A N8487A N8486AR N8486AQ
100 kHz to
10 MHz – – – 0.91 1.48 0.89 – – – –
10 MHz to
30 MHz 0.82 1.42 0.77 0.78 1.43 0.79 0.82 – – –
30 MHz to
500 MHz 0.77 1.48 0.89 0.77 1.49 0.89 1.24 1.33 – –
500 MHz to
1.2 GHz 0.78 1.48 0.89 0.78 1.49 0.89 1.26 1.35 – –
1.2 GHz to
6 GHz 0.91 1.58 1.06 0.89 1.56 1.02 1.35 1.41 – –
6 GHz to
14 GHz 1.26 1.77 1.46 – – – 1.66 1.61 – –
14 GHz to
18 GHz 1.59 1.92 1.73 – – – 1.83 1.73 – –
18 GHz to
26.5 GHz – – – – – – 2.67 2.26 – –
26.5 GHz to
33 GHz – – – – – – 3.32 2.58 2.68 –
33 GHz to
34 GHz – – – – – – – 2.80 3.19 3.14
34 GHz to
35 GHz – – – – – – – 2.80 3.19 3.40
35 GHz to
40 GHz – – – – – – – 2.80 3.19 3.14
40 GHz to
45 GHz – – – – – – – 3.66 – 3.19
45 GHz to
50 GHz – – – – – – – 4.23 – 3.26
