Series Modules
Analog output module
2 channel TRION™ analog output module, based on NI PXI-6251
voltage range max. ±10 V
16 bit resolution
Update rate max. 2.8 MS/s
TRION-1628-AO
-2
TRION-1628-AO-2
TRION-1628-AO-2 specifications
Analog input channels
2
DAC resolution
16 bits
DNL
±1 LSB
Monotonicity
16 bit guaranteed
Accuracy
Nominal Range
Residual
Gain Error
(ppm of
Reading)
Gain
Tempco
(ppm/°C)
Reference
Tempco
Residual
Offset Error
(ppm of
Range)
Offset
Tempco
(ppm of
Range/°C)
INL
Error
(ppm of
Range)
Absolute
Accuracy at
Full Scale1
(µV)
Positive
Full
Scale
Negative
Full
Scale
10
-10
75
17
1
40
2
64
2,08
5
-5
85
8
1
40
2
64
1,045
Maximum update rate
1 channel
2.86 MS/s
2 channels
1.00 MS/s
Timing accuracy
50 ppm of sample rate
Timing resolution
50 ns
Output range
±10 V, ±5 V
Output coupling
DC
Output impedance
0.2 Ω
Output current drive
±5 mA
Overdrive protection
±25 V
Overdrive current
20 mA
Power-on state
±5 mV2
Power-on glitch
1.5 V peak for 1.5 s
Output FIFO size
8,191 samples shared among channels used
Settling time, full scale step 15 ppm (1 LSB) 2 µs
Slew rate
20 V/µs
Glitch energy at midscale transition,
±10 V range
Magnitude
10 mV
Duration
1 µs
