www.dewetron.com
10
DEWE2
A ll-In-One
Instruments
DEWE2-A4 DEWE2-A7 DEWE2-A13
Slots for TRION™ acquisition modules 4 7 13
Dynamic channel expansion Ethernet Ethernet Ethernet
Quasi-static channel expansion
EPAD2
CPAD2 via TRION-CAN
EPAD2
CPAD2 via TRION-CAN
EPAD2
CPAD2 via TRION-CAN
Data storage 1)
Technology Removable Solid State Disk (SLC type) Hard disk Hard disk
Capacity 120 GB (up to 256 GB) 1 TB 1 TB
Typ. duration of recording
(16 ch. / 10 kS/s/ch. / 16 bit)
1 day 35 days 35 days
Gap free storing rate 2) Typ. 90 MB/s Typ. 90 MB/s Typ. 90 MB/s
Main system 1)
Display 13“ (1280 x 800) 17“ (1920 x 1080) 17“ (1920 x 1080)
Processor Intel ® Core™ i7 Intel ® Core™ i7 Intel ® Core™ i7
Power supply
Input voltage: rated (max.)
11 to 32 V
DC
(10 to 36 V
DC
) isolated
incl. external AC power supply
100 to 240 V
AC
(90 to 264 V
AC
) 100 to 240 V
AC
(90 to 264 V
AC
)
Optional
Add internal buffer battery
for ~ 10 min. operation and/or
DW2-UPS-150-DC (ext. battery pack)
Battery powered, 3 battery slots 3) ,
3 batt. for ~2 hours operation included,
incl. external AC power supply,optional
external DC power supply
Battery powered, 3 battery slots 3) ,
3 batt. for ~2 hours operation included,
incl. external AC power supply,optional
external DC power supply
Environmental
Operating temperature
0 to +50 °C, down to -20 °C with
prewarmed unit
0 to +50 °C, down to -20 °C with
prewarmed unit
0 to +50 °C, down to -20 °C with
prewarmed unit
Storage temperature -20 to +70 °C -20 to +70 °C -20 to +70 °C
Humidity
10 to 80 % non cond.,
5 to 95 % rel. humidity
10 to 80 % non cond.,
5 to 95 % rel. humidity
10 to 80 % non cond.,
5 to 95 % rel. humidity
Max. Altitude 2000 m (6560 ft) 2000 m (6560 ft) 2000 m (6560 ft)
Sine vibration (EN 60068-2-6) 20 m/s² 20 m/s² 20 m/s²
Shock (EN 60028-2-27) 30 g 15 g 15 g
Random vibration (EN 60721-3-2) Class 2M3 Class 2M2 Class 2M2
Dimensions
Dimensions (W x D x H)
(without handle)
318 x 253 x 128 mm
(12.5 x 10 x 5 in.)
450 x 246 x 303 mm
(17.7 x 9.7 x 11.9 in.)
450 x 246 x 303 mm
(17.7 x 9.7 x 11.9 in.)
Weight without TRION™ modules Typ. 5.9 kg (13 lb.) Typ. 14 kg (31 lb.) Typ. 15 kg (33 lb.)
1) Please find current specifications in the latest price list
2) Depending on configuration (performance is different if e.g. Video data is involved and 2 or more files are written in parallel)
3) Weight of one battery: 660 g (1.45 lb.)
DEWE2 All-in-One Instruments
DW2-UPS-150-DC
The hot-swappable
batteries guarantee
continuous operation with-
out an external power source.
A-series
DEWE2-A7
DEWE2-A4 with
Removable Solid State Disk DEWE2-A13
