ARINC 429 module with up to 30 interfaces
MIL-STD-1553 modules with up to 4 dual redundant channels
Mixed modules with 8 ARINC and up to 5 dual redundant MIL-STD-1553 channels
Specifications
Ports
TRION-A429
TRION-M1553
TRION-MA4
4, 8, 16 or 30 ARINC 429
1 to 4 MIL-STD-1553
8 x ARINC 429 + 1 to 5 MIL-STD-1553
Resolution 8 bit, 1 uSec A/D signal capture on first two RX channels
Programmable interface
Fully programmable label/word encoding and decoding
Word length, Start/Sync/Stop bits, MSB/LSB, RX/TX bit (baud) rates, parity, bit encoding types
Memory One Mbyte of memory per 16 channel bank for TX/TX buffering
Power consumption [email protected], [email protected], [email protected], [email protected]
Connector SCSI 3 connector, cable provided
Temperature range 0 to +50°C
Weight Appr. 120 g
TRION-A429
TRION-A429 / M1553 / MA4
Series Modules
TRION Module ARINC channels 1553 channels
TRION-A429 modules
A429-4-T
4 (shared Tx/Rx) -
A429-8-T 8 (shared Tx/Rx) -
A429-16-T 16 (8 shared Tx/Rx and 8 Rx) -
A429-30-T 30 (16 shared Tx/Rx and 14 Rx) -
TRION-M1553 modules
M1553-1D-T
- 1 dual redundant, dual function
M1553-2D-T - 2 dual redundant, dual function
M1553-4D-T - 4 dual redundant, dual function
M1553-1F-T - 1 dual redundant, full function
M1553-2F-T - 2 dual redundant, full function
M1553-4F-T - 4 dual redundant, full function
TRION-MA4 modules
MA4-1D8-T
8 (4 shared Tx/Rx and 4 Rx) 1 dual redundant, dual function
MA4-2D8-T 8 (4 shared Tx/Rx and 4 Rx) 2 dual redundant, dual function
MA4-4D8-T 8 (4 shared Tx/Rx and 4 Rx) 4 dual redundant, dual function
MA4-5D8-T 8 (4 shared Tx/Rx and 4 Rx) 5 dual redundant, dual function
MA4-1F8-T 8 (4 shared Tx/Rx and 4 Rx) 1 dual redundant, full function
MA4-2F8-T 8 (4 shared Tx/Rx and 4 Rx) 2 dual redundant, full function
MA4-4F8-T 8 (4 shared Tx/Rx and 4 Rx) 4 dual redundant, full function
MA4-5F8-T 8 (4 shared Tx/Rx and 4 Rx) 5 dual redundant, full function
Model overview
