PCIe connection up to 7 meters TRION-SYNC-bus
DEWE2-F18 with option
DW2-LINK-PCIE-2-S
DEWE2-M13 with
TRION-TIMING module
and LINK-HOST-PCIE card
www.dewetron.com
20
DEWE2-M13
13 slots for TRION™ series modules
Free PCI slots inside
One internal hard disk and 2 bays for removable disks
19” rack-mountable or benchtop use
DEWE2-M13
Slots for TRION™ modules 13
Dynamic channel expansion Ethernet
Quasi-static channel expansion
EPAD2
CPAD2 via TRION-CAN
Main system 1)
Free slots (PCI, PCIe) 2 PCI, 1 PCI x4, 1 PCI x16
Data storage
1 TB hard disk
2 free 3.5” bays for further hard disks
Gap free storing rate Typ. 80 MB/s 2)
Power supply: rated (max.) 100 to 240 V
AC
(90 to 264 V
AC
)
Display no display
Processor Intel ® Core™ i7
RAM 4 GB
Ethernet 2x 1 Gbit Ethernet
USB interfaces 8
FireWire ® interface optional
Keyboard/pointing device external keyboard with touchpad
Operating system Microsoft ® WINDOWS ® 7
Dimensions (W x D x H)
without feet
441 x 427 x 177 mm (4 u plus 1 u for cooling in cabinet required)
(17.4 x 16.8 x 7 in.)
Weight Typ. 13.0 kg (28.6 lb.)
Power consumption without modules Typ. 100 W
Environmental specifications
Operating temperature
0 to +50 °C, down to -20 °C with prewarmed unit
Storage temperature -20 to +70 °C
Humidity 10 to 80 % non cond., 5 to 95 % rel. humidity
Max. Altitude 2000 m (6560 ft)
Sine vibration (EN 60068-2-6) Acceleration 20 m/s², Freq. 10 Hz - 150 Hz, Sweep 1 oct/min, 20 cycles
Shock (EN 60028-2-27) Acceleration 15 g, pulse length 11ms, pulse form half sine, 3 moves/direction, 6 directions
Random vibration (EN 60721-3-2) Class 2M2 (spectral acceleration density 1 m²/s³, Frequency range 10 Hz-200 Hz, duration 30 min/direction)
1) Please find current specifications in the latest price list
2) Depends on the system configuration
DEWE2-M13
Channel Expansion
