Page 20
Reception measur
ement
20
◆ MX880131A PDC Measurement Software (extracts)
Transmission measur
ement
Reception measur
ement
◆ MX880132A PHS Measurement Software (extracts)
Transmission measur
ement
Reception measur
ement
Frequency/
Frequency range: 10 MHz to 2.2 GHz
modulation
Modulation accuracy: ±(2% of indicated value + 0.5%)
measurement
Amplitude
Input level range: +10 to +40 dBm (average power with burst, MAIN connector)
measurement
Transmitter power accuracy: ±10% (MAIN connector, after calibration by using built-in power meter)
Adjacent channel
power measurement
Measurement range:
Ն
60 dB (50 kHz offset),
Ն
65 dB (100 kHz offset)
Batch measurement
Measurement time:
Յ
1.5 s (amplitude measurement in normal mode; occupied bandwidth and adjacent
functions
channel power measurement on high-speed mode)
Frequency range: 10 MHz to 3 GHz
Signal generator
Level range: –133 to –13 dBm (MAIN connector), –133 to +7 dBm (AUX connector)
Modulation accuracy:
Յ
3%rms
Error rate
Measurement pattern: PN9, PN15
measurement
Number of measurement bits: 10
2
, 10
3
, 2556, 10
4
, 10
5
, 10
6
,
∞
Frequency/
Frequency range: 10 MHz to 2.2 GHz
modulation
Modulation accuracy: ±(2% of indicated value + 0.7%)
measurement
Amplitude
Input level range: +10 to +40 dBm (average power with burst, MAIN connector)
measurement
Transmitter power accuracy: ±10% (MAIN connector, after calibration by using built-in power meter)
Adjacent channel
Measurement range:
Ն
60 dB (600 kHz offset),
Ն
65 dB (900 kHz offset)
power measurement
Batch measurement
Measurement time:
Յ
1.5 s (amplitude measurement in normal mode; occupied bandwidth and adjacent
functions
channel power measurement on high-speed mode)
Frequency range: 10 MHz to 3 GHz
Signal generator
Level range: –133 to –13 dBm (MAIN connector), –133 to +7 dBm (AUX connector)
Modulation accuracy:
Յ
3%rms
Error rate
Measurement pattern: PN9, PN15
measurement
Number of measurement bits: 10
2
, 10
3
, 2556, 10
4
, 10
5
, 10
6
,
∞
◆ MX880118A DECT Measurement Software (extracts)
T
ransmission measur
ement
Frequency/
Frequency: 10 MHz to 2.2 GHz
modulation
RF carrier accuracy: ±250 Hz + reference oscillator accuracy
measurement
Frequency drift measurement accuracy: ±250 Hz
Modulation measurement accuracy: ±10 kHz
Input level range: –5 to +40 dBm (MAIN connector)
Amplitude
Calibration input level range: +15 to +40 dBm (MAIN connector)
measurement
Transmitter power accuracy: ±0.4 dB (+15 to +40 dBm), ±0.7 dB (–5 to +15 dBm)
∗
MAIN connector, after calibration by using built-in power meter
Emission due to modulation:
–8 dBm/160
W at M ±1, –30 dBm/1
W at M ±2, –44 dBm/40 nW at M ±3,
Adjacent channel
–47 dBm/20 nW at M ±4 and M ±5
power measurement
Emission due to transmitter transient:
–6 dBm/250
W at M ±1, –13 dBm/40
W at M ±2, –23 dBm/4
W at M ±3,
–30 dBm/1
W at M ±4 and M ±5
All measurement
Frequency, deviation, frequency drift, Tx power, carrier-off power, template pass/fail, timing, adjacent channel emission
items
Frequency range: 10 MHz to 3 GHz
Signal generator
Level range: –133 to –13 dBm (MAIN connector), –133 to +7 dBm (AUX connector)
Modulation error:
Ϲ
±8% (at 288 kHz deviation, frequency: 10 MHz to 2.2 GHz)
Modes: FER, BER (quick mode), BER (full mode)
Measurement pattern:
Error rate
0000111100001111, 0011001100110011, 0101010101010101, 1010 64
✕
1 64
✕
0 1010,
measurement
pseudorandom (D-2M), ETSI patterns
Number of measurement bits: 1 k to 99000 k
Call processing
Bearer setup, bearer release, hand-over loop back
