30 031-124-C0-004, Rev. D
2.0 Installation, continued
2.10 Enclosure Protection
Alpha Technologies cannot anticipate all of the ways a vehicle may potentially threaten an
installed system, or the specifi c type of protection that is appropriate for a particular location.
The determination of the threat to the equipment and the means of protection are the
responsibility of the end user of the equipment. The following installation drawing is a general
recommendation and not intended to be a specifi c guideline for protecting the equipment. The
numbers of bollard posts (or other protection devices) depend upon equipment locations, site
surveys, traffi c patterns and local codes. Do not install enclosure within 10' (3m) of a water
sprinkler to prevent water from entering enclosure.
SIDEWALK
PAD
POSTS
Sprinkler
Head
Fig. 2-11, Bollard Placement
10' (3m)
min.
