26

031-124-C0-004, Rev. D

Fig. 2-7, Flag Battery Terminal Connections

2.0 Installation,

continued

2.9

Battery Installation, continued

2.9.3

Battery Terminal Connections, continued

1" (25.4mm) x 1/4-20 Bolt

Split Washer

Flat Washer

Battery Sense Cable

Battery Cable

Battery Terminal

Flat Washer

Nut

Flag Terminals

Nut

Split Washer

Flat Washer

Battery Cable

In-Line Fuse Link

Flat Washer

1" (25.4mm) or 3/4" (19mm) x 1/4-20 Bolt

1" (25.4mm) x 1/4-20 Bolt

Flat Washer

Split Washer

Spacer

Battery Terminal

Fuse
