Alpha Technologies UPE-6 User Manual
Page 19
19
031-124-C0-004, Rev. D
Fig. 2-2, Typical Service Entrance Wiring
240 Vac Service Entrance
120Vac Service Entrance
2.0 Installation,
continued
2.6
Utility Power Connection, continued
ON
OFF
Ground
From Utility
Line 1
Line 2
Neutral
Optional Line
Surge Arrester
To Enclosure
ON
OFF
From Utility
Line 1
Optional Line
Surge Arrester
To Enclosure
Ground
Neutral
