Alpha Technologies UPE-6 User Manual
Page 12
12
031-124-C0-004, Rev. D
Fig. 1-5, Typical Site Arrangement for Pedestal and Cover
1.0 Introduction,
continued
1.2
Precast Pad and Pedestal Mounting Options, continued
For detailed installation instructions, refer to the Manufacturer’s Installation Documentation included
with the pedestal support package.
Grade
Undisturbed
Ground
Backfill
Pad/Pedestal
Compacted
Gravel
