Alpha Technologies DSM3 for XM3 - Technical Manual - Manual (Page 87)

87 745-814-B11-001, Rev. C (03/2014)
10.1 Definitions and Settings
Parameter OID Description Access Type Value
CPE SETTINGS (Dual IP )
atiMgmtSysMonitoringCpeStaticMode 1.3.6.1.4.1.926.1.3.2.2.5.2.1.0 Method by which the CPE acquires its
IP address
Read/Write Integer 1=DHCP
2=Static
atiMgmtSysMonitoringCpeStaticAddress 1.3.6.1.4.1.926.1.3.2.2.5.2.2.0 When the address source is static,
this is the IP address the CPE will be
assigned.
Read/Write IP Address 0.0.0.0 (default)
atiMgmtSysMonitoringCpeStaticMask 1.3.6.1.4.1.926.1.3.2.2.5.2.3.0 When the address source is static,
this is the mask the device will use to
determine if other devices are on the
local area network (LAN).
Read/Write IP Address 0.0.0.0 (default)
atiMgmtSysMonitoringCpeStaticGateway 1.3.6.1.4.1.926.1.3.2.2.5.2.4.0 When the address source is static, this
is the IP address of the gateway the
device will use for accessing devices
not on the local area network (LAN).
Read/Write IP Address 0.0.0.0 (default)
COMMUNITY STRINGS
atiMgmtSnmpCommunities
1.3.6.1.4.1.926.1.3.1.4.0 Object Identifier
atiMgmtSnmpCommGet 1.3.6.1.4.1.926.1.3.1.4.1.0 Default "Read" Community String Read/Write Octet String AlphaGet (default
atiMgmtSnmpCommSet 1.3.6.1.4.1.926.1.3.1.4.2.0 Default "Read/Write" Community String Read/Write Octet String AlphaSet (default)
SNMP TRAP
atiMgmtSnmpControls
1.3.6.1.4.1.926.1.3.1.5 Object Identifier
atiMgmtSnmpTrapOnNormal 1.3.6.1.4.1.926.1.3.1.5.1.0 Traps sent when an item in an alarm
state returns to normal
Read/Write Integer 1 = Disable
2 = Enable (default)
atiMgmtSnmpSendCount 1.3.6.1.4.1.926.1.3.1.5.2.0 Number of times a trap is to be sent/
repeated
Read/Write Integer 1 to 9
1 (default)
atiMgmtSysSnmpTimeout 1.3.6.1.4.1.926.1.3.1.5.3.0 The number of minutes allowed to pass
without SNMP communications. On the
lapse of this many minutes the device
will reset. Setting this value to zero will
prevent timeout resets.
Read/Write Integer 0 to 65,000 (in minutes)
1440 (default)
SOFTWARE DOWNLOAD
atiMgmtSys
1.3.6.1.4.1.926.1.3.2.0 Object Identifier
atiMgmtSysDownload 1.3.6.1.4.1.926.1.3.2.1.0 Object Identifier
atiMgmtSysDownloadTftpAddress 1.3.6.1.4.1.926.1.3.2.1.1.0 DSM Firmware TFTP Server Address Read/Write IP Address 0.0.0.0 (default)
atiMgmtSysDownloadCtrl 1.3.6.1.4.1.926.1.3.2.1.2.0 DSM Firmware Download "Trigger" Read/Write Integer 1: readOneNext(1)
2: readTwoNext(2)
3: idle(3)
4: abort(4)
5: psReprogram(5)
atiMgmtSysDownloadStatus 1.3.6.1.4.1.926.1.3.2.1.3.0 DSM Firmware download Status Read Only Integer 1=Idle (default)
2=Ready
3=Request
4=Requested
5=Transferring
6=Testing
7=Data Done
8=Error
9=Closing
atiMgmtSysDownloadFile1 1.3.6.1.4.1.926.1.3.2.1.4.0 DSM Firmware Filename Read/Write Octet String DSM firmware filename
atiMgmtSysDownloadFile2 1.3.6.1.4.1.926.1.3.2.1.5.0 Reserved Read/Write Octet String
atiMgmtSysDownloadProgress 1.3.6.1.4.1.926.1.3.2.1.6.0 Download Progress in Bytes Read Only Integer 0:0..100000
atiMgmtSysDownloadSysDescr 1.3.6.1.4.1.926.1.3.2.1.7.0 DSM Firmware description used for
upgrades
Read/Write Octet String i.e. "ATI P01V01.12.0 "
(legacy DSMs)
atiMgmtSysDownloadSysObjectId 1.3.6.1.4.1.926.1.3.2.1.8.0 DSM Hardware Identifier used for
upgrades
Read/Write Object Identifier 1.3.6.1.4.1.926.1.99.1.1.1.0
atiMgmtSysDownloadConfigName 1.3.6.1.4.1.926.1.3.2.1.9.0 DSM Setup File Filename Read/Write Octet String atidoc03.cfg
atiMgmtSysDownloadConfigAddress 1.3.6.1.4.1.926.1.3.2.1.10.0 DSM Setup File TFTP location Read/Write IP Address 0.0.0.0 (default)
atiMgmtSysDownloadCm 1.3.6.1.4.1.926.1.3.2.1.11.0 Force DSM Download from modem's
docsDevSwServerIp (Dual IP)
Read/Write Integer "1=Auto (default)
2=ForceCM"
10.0 Alpha MIB Parameters
