6.2.1 SCTE-HMS Configurable Alarms, continued
Table 6-3, Recommended Settings for DSM3 Series Analog Alarms
Analog Alarms and Common Settings
Analog Alarms Description
Alarm
Enable
LOLO LO HI HIHI Deadband
psTotalStringVoltage 36V
Scaled representation of the full
battery string in 1/100 Volts units
0x0F 3300 3500 4520 4570 50
Individual Battery Voltage
Battery Voltage of 12V Battery in
1/100 Volts units
0x0F 1050 1150 1530 1550 20
psInputVoltage
120V
Scaled representation of the input
line voltage in 1/100 Volts units
0x0F Varies by site. The XM3 will switch to standby at
nominal +15% -30% 220V 0x0F
psRMSCurrentIn
Scaled representation of the Power
Supply's RMS curent in 1/100 A
units
0x00 Set as desired per site
psPowerIn
Representation of the Power
Supply's input power in 1 W units
0x00 Set as desired per site
psFrequencyOut
Representation of Power Supply's
output frequency in 1/100 Hz units
0x00 Set as desired per site
psOutputVoltage
Scaled representation of the Power
Supply output voltage in 1/100
Volts units
0x0F 4300 4550 5050 5300 200
0x0F 5650 6000 6600 7000 200
0x0F 7800 8200 9150 9300 200
psPowerOut
Representation of Power Supply
output power in 1W units
0x00
It is recommended that psOutputCurrent be used
for output alarms.
psStringChargeCurrent
Battery string charge current,
scaled in 1/100 Amp units
0x0C Disable Disable 1200 1250 20
psStringDischargeCurrent
Scaled representation of battery
string discharge current. This is an
RMS value in 1/100 Amps
0x00 Set as desired per site
psStringFloat
Battery string float charge current,
scaled in 1/100 Amp units
0x0C Disable Disable 1200 1250 20
psOutputCurrent
15A
Scaled representation of Power
Supply RMS currnt in 1/100 Amp
units
0x0C Disable Disable 1650 1720 20
18A 0x0C Disable Disable 1980 2060 20
22A 0x0C Disable Disable 2420 2530 40
psTemperature -40 to +80 degrees C 0x0F Varies by site
docsIfDownChannelPower
The CM's receive RF power scaled
in 1/10 dBmV units
0x0F -150 -10 10 150 15
docsIfCmStatusTxPower
The CM's transmit RF power
scaled in 1/10 dBmV units
0x0C 0 0 500 550 15
atiBBsysViewTimeInStandby
Time in seconds that the Power
Supply's inverter is currently
running due to outage or self test
0x0C 0 0
Set as
desired for
notification
of extended
outage
10
Alarms for Optional Generator
GenVBatIgnition
Scaled representation of the
generator's ignition battery in
1/100 Volts
0x0F 1150 1200 1500 1550 20
genEnclosureTemperature
Temperature inside generator's
enclosure in degrees C
0x09 -40 0 0 55 5
The following table displays the various analog alarms with common settings for the DSM3 Series
Communications Module.
