16 745-814-B11-001, Rev. C (03/2014)
3.3.4 Setting SNMP Trap Destination Addresses — DOCSIS 2.0+IPv6 Method
Set the SNMP Trap Destination Addresses via the DOCSIS Configuration File by including the
following SNMP parameters:
3.0 Network Configuration
TLV Type TLV Parameter Description Value
38 SNMPv3 Notification Receiver This config file element specifies a
Network Management Station that will receive
notifications from the modem when it is in
Coexistence mode. Up to 10 of these elements
may be included in the configuration file.
Composite
38.1 SNMPv3 Notification Receiver IP
Address
This sub-TLV specifies the IP address of the
notification receiver.
0:0:0:0:0:0:0:0
e.g.fc00:168:1:0:0:0:0:32
0.0.0.0
e.g. 10.11.0.1
38.2 SNMPv3 Notification Receiver UDP Port
Number
This sub-TLV specifies the UDP port number
of the notification receiver. If this sub-TLV is not
present, the default value of 162 should be used.
UDP port number
e.g. 162
38.3 SNMPv3 Notification Receiver Trap
Type
This sub-TLV specifies the type of trap to send. The trap type may take values:
1 = SNMP v1 trap in an SNMP v1 packet
2 = SNMP v2c trap in an SNMP v2c packet
3 = SNMP inform in an SNMP v2c packet
4 = SNMP v2c trap in an SNMP v3 packet
5 = SNMP inform in an SNMP v3 packet
38.4 SNMPv3 Notification Receiver Timeout This sub-TLV specifies the timeout value to
use when sending an Inform message to the
notification receiver.
Time in milliseconds
e.g. 15000
38.5 SNMPv3 Notification Receiver Retries This sub-TLV specifies the number of times
to retry sending an Inform message if an
acknowledgement is not received.
Number of retries
e.g. 3
38.6 SNMPv3 Notification Receiver Filtering
Parameters
Object Identifier of the snmpTrapOID value
that identifies the notifications to be sent to the
notification receiver. This notification and all
below it will be sent.
Filter OID
e.g. 1.3.6
Table 3-4, Trap Destination Addresses — DOCSIS 2.0+IPv6 Method
As an alternative to the docsDevNmAccessTable or SNMPv3 trap parameters, SNMP Trap
Destination Addresses may be set through the DSM3 proprietary MIB atiMgmtSnmpTrapTable (OID:
1.3.6.1.4.1.926.1.3.1.1) using a SNMP MIB Browser or as an entry in the Proprietary Configuration File
‘atidoc03.cfg’ in Section 3.3.6, Sample DOCSIS Configuration File Entries — DOCSIS 2.0+IPv6.
NOTE:
