Ts-ra2, Ts-rk – Franklin Fueling Systems TS-RA2 User Manual
Page 7
7
1-1 LINE
1-2 NEUTRAL
2-1
2-2
2-3
2-4
1-6 FLASH DRIVE
1-7 FLASH SHUNT
1-8 OUTPUT
1-9 OUTPUT RETURN
1-3 GROUND
1-4
1-5
REMOTE ALARM SIGNAL
ACKN
SWITCH
LATCH
MODE
NC1
C1
NO1
NC2
C2
NO2
TS-RA2
TS-RK
To 110 VAC
Power Supply
N STB L
N AUD L
SW1
1 2 3 4
O
N
2AG 3A Fuse
Console Relay Outputs
TS-RK and TS-RA2 Wiring Schematic
TS-RA2 SW1 Switch Position Settings
(factory settings are shown in bold italic)
Sound Ouput
Level
Position 1 Tone
Pos. 2
Pos. 3 Pos. 4
High dB
ON
Horn
(continuous)
ON
ON
ON
Standard db
OFF
Bell
ON
OFF
ON
March Time Horn OFF
OFF
ON
Code-3 Horn
ON
ON
OFF
Code-3 Tone
OFF
ON
ON
Slow Whoop
OFF
ON
OFF
Siren
ON
OFF
OFF
HI/LO
OFF
OFF
OFF
See Table below
