Franklin Fueling Systems TSP-DVS User Manual
Page 4
©2008 FFS 000-1350 Rev D
Sensor
Channel # / Notes
Under setup / 3-wire Modules, assign unique names for the sensors
The Vapor reading indicates the normal vapor level in the space being monitored. Under FMS / Control / Sensors, set the
vapor offset to a value that will trigger a vapor alarm. Typical values are between 200 and 300. The presence of significant
vapors will create a drastic increase in the vapor reading.
Programming T5 Series Consoles (other consoles use similar configuration)
