Standard Installation Materials
Circuit Breaker
20 Amp — providing power only for the console
Weatherproof Junction Boxes
Minimum 16 cubic inch (406.4 cubic mm) weatherproof
junction box, cover, and cover gasket for the manholes of
liquid level probes. Also use ½ inch (16 mm) bushings for
probe compression fittings.
Use a weatherproof metal pull box for combining several
circuits that will run into the console through one or more
conduits.
Use a separate weatherproof metal pull box to combine
intrinsically safe (IS) liquid level probe wiring. Do not run
other non-intrinsically safe wiring within the IS pull box.
Run ½ inch (16 mm) IS probe conduit from the manholes
to the IS pull box, and then run one or two ½ inch (16 mm)
conduits to the console’s IS conduit knockouts.
Conduit
Rigid metal conduit (RMC) - male NPT threaded: use
½ (16 mm) for IS probe wiring to the console (from the
manholes, use ½ inch conduit), and use ½ inch (16 mm)
for non-intrinsically safe accessories and power wiring.
Use conduit hardware that is appropriate for the installation
and meets local, state and federal requirements.
Splice Connector Kits Must Be Used —
Warranty Requirement
Use the FFS-approved, moisture-resistant, no-strip splice
connectors for liquid level probes. You may order the
TSP-KW30, which contains 30 of the FFS-approved,
moisture-resistant connectors.
Using moisture resistant splice connectors will:
• Reduce / eliminate corrosion of the wire connections from
repeated exposure to water condensation, which causes
eventual signal loss and system failure.
• Reduce or eliminate equipment damage from water
flooding around the connectors, which causes short-
circuit damage.
Thread Sealant (UL Classified)
Use a non-hardening, “stay-soft,” Teflon thread sealant,
or equivalent, to seal and waterproof all tank riser pipe
threads. In addition, the thread sealant (or “pipe dope”
as it is commonly known) should also be chemically
non-reactive to the product in the tank(s). Apply thread
sealant to seal / waterproof all outdoor electrical conduit
fitting threads including the hole plugs at the weatherproof
junction boxes.
Riser Pipes
ANSI Schedule 40 (or chemically non-reactive) 2" or 4"
(50.8 or 101.6 mm) (8 NPT) riser pipes for liquid level
probes.
Probe Installation Kit(s)
The appropriate FFS 2” or 4” probe installation kit must
be used when installing TSP-LL2 (not -I) leak detection
probes and / or Density Measurement float kits.
Probe Install Kits:
Part # Description
TSP-K2A For 2" riser pipes, NPT
TSP-K2B For 2" riser pipes with BSP threads
TSP-K4A For 4" riser pipes, NPT
TSP-K4S 316 stainless steel for 4" riser pipes, NPT
TSP-K4B For 4" riser pipes with BSP threads
Probe Floats
• Floats for 4 inch (101.6 mm) riser pipes, order: TSP-
IGF4 for gasoline applications or TSP-IDF4 for diesel
and fuel oil
• Floats for 3 inch (76.2 mm) riser pipes, order: TSP-IGF3
for gasoline applications or TSP-IDF3 for diesel and fuel oil
• Floats for 2 inch (50.8 mm) riser pipes, order: TSP-IGF2
for gasoline, TSP-IDF2 for diesel and fuel oils, or
TSP-SSP stainless steel float for chemical products
• Density floats for 4 inch (101.6mm) riser pipes, order:
TSP-IGF4D for gasoline applications and TSP-IDF4D
for diesel and fuel oil.
Manufacturer’s Tank Chart for Each Tank
The manufacturer’s Tank Chart and other documentation
will be used for installation and programming, and possibly
for future reference. Keep this information — do not
discard it.
