Console dimensions, Figure 2: console dimensions – Franklin Fueling Systems Colibri CL6 Installation Guide User Manual
Page 6
3
Console Dimensions
Figure 2: Console Dimensions
(235 mm)
9.25"
1.00"
(25.4 mm)
2X 0.21"
(5.33 mm)
Ground stud
See note 2.2
Intrinsically
safe wiring
compartment
Power / relay
Compartment
Probe Interface
Connections
11.92" (303 mm)
7.27"
(185 mm)
Alarm Led
Warning Led
Power Led
LCD Display
(Optional)
Communication Ports
Non-Intrinsically Safe Conduit Entries
2.24"
(57 mm)
Cover Release Tab
Both Ends
Intrinsically Safe Conduit Entries
