SW HDMI LC • Reference Information
22
Reference
Information
This section reference information for the SW HDMI LC switchers. Topics that are covered
include:
z
z
z
z
z
z
Specifications
NOTE: *Appropriate HDMI to DVI-D cables or adapters are required for DVI signal input/output.
Video
Maximum data rate .................. 6.75 Gbps (2.25 Gbps per color)
Maximum pixel clock ................ 225 MHz
Resolution ................................ Up to 1080p @ 60 Hz or 720p/1080i @ 120 Hz, 12-bit color
Formats .................................... RGB, YCbCr, and xvYCC digital video
Standards ................................. DVI 1.0, HDMI 1.3, HDCP, CEA-861E
Video input
Number/signal type................... 2 or 4 single link HDMI (or DVI-D*)
Connectors ............................... 2 or 4 female HDMI type A
Input equalization ..................... +6 dB or +18 dB, selectable for each input
Video output
Number/signal type................... 1 single link HDMI (or DVI-D*)
Connectors ............................... 1 female HDMI type A
Control/remote — switcher
Serial control port ..................... (1) RS-232, 3.5 mm captive screw connector, 5 pole (shared with auto-
input switching control)
Baud rate and protocol ............. 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations 1 = Tx, 2 = Rx, 3 = GND
Contact closure ........................ (1) 3.5 mm captive screw connector, 5 pole (shared with RS-232)
Contact closure pin configurations
Pins 4 and 5 shorted together turn auto-input switch mode on.
IR controller module ................. IR 102 remote control (optional)
30' maximum, 40 degrees off axis
Program control ........................ Extron Simple Instruction Set
™
(SIS
™
)
