Operation, cont’d
CrossPoint 450 Plus and MAV Plus Switchers • Operation 3-4
Input and output buttons
Primary functions
Action Select an input or output for a tie being created.
Indications Blinking : potential tie/untie
Lit : current tie
Amber : video and audio tie
Green : video only tie
Red : audio only tie
1 2 3
through up to
64
Secondary functions
I/O Grouping Action 1 Input 1 and Output 1 :
Select I/O Group mode.
Action 2 Assign an input or output to the selected group.
Indication Lit : Input or output is assigned to the selected group.
Presets Action Select a preset in Preset mode.
Indication Lit : A preset has already been saved to this location.
Blink : Preset location is selected to be saved.
RGB Delay Indication Systems with CrossPoint Wideband BMEs:
Input 1 through 10 : Indicate the RGB delay.
Input audio
level
Action
(inputs) Systems with audio BMEs:
Select the input’s audio for gain or attenuation adjustment.
Indication
(inputs) Input’s audio is selected for adjustment.
Indication
(outputs) Indicate the input gain or attenuation level.
Output audio
volume
Action
(outputs) Systems with audio BMEs:
Select the output’s audio for volume adjustment.
Indication
(outputs) Output’s audio is selected for adjustment.
Indication
(inputs) Indicate the output volume level.
Mutes Action
(outputs) Press and hold to mute the video and audio, video, or audio output.
Indication
(outputs) Blinking : Output is muted.
Background
illumination
Action Input 1 and Input 2 :
Toggle between background illumination
or buttons unlit.
