Installation, cont’d
CrossPoint 450 Plus and MAV Plus Switchers • Installation
2-12
Terminate cable or
connect to another device.
Connect to
MAV Plus 6464.
Tee connector
OUT
Extron
MAV Plus 6464
Matrix Switcher
Extron
BBG 6 A
Black Burst Color Bar
Audio Generator
Figure 2-12 — Simple external sync connection example
Figure 2-13 shows another configuration, in which the timing source passes
through three video cameras and a video scan converter before connecting
to the switcher. This type of video camera can synchronize with the external
timing source for video editing applications.
Video Camera
Video Camera
Video Camera
Monitor
VCR
Extron
MAV Plus 6464
Matrix Switcher
Extron
BBG 6 A
Black Burst/Color Bar/
Audio Generator
Extron
VSC 900D
Computer-to-Video
Scan Converter
VGA Input
50/
60
Hz
100
-24
0V
0.3
A
R
/R-
Y
R
/R-
Y
I
N
P
U
T
S
O
U
T
P
U
T
S
G
/Y
2
RG
B/R
-Y,
B-Y
, Y
RG
B
1
G-Y
B
/B-
Y
B
/B-
Y
H
/HV
H
/HV
V
V
VID
EO
S-VIDEO
D1
R/R
-Y
G/Y
B/B
-Y
H/H
-Y
RS
-23
2
/42
2
G
E
N
L
O
C
K
V
IN
OU
T
DIS
TR
IBU
TIO
N A
MP
LIF
IER
Figure 2-13 — Multiple device external sync connection example
Power
l
AC power connector — Plug a standard IEC power cord into this connector to
connect the switcher to a 100 VAC to 240 VAC, 50 or 60 Hz power source.
