Page 105

4-17
CrossPoint 450 Plus and MAV Plus Switchers • Programmer’s Guide
Command/response table for SIS commands (continued)
N
X@
= Output number
01 – (maximum number of outputs for your model)
X$
= Input number
01 – (maximum number of inputs for your model)
X(
= Global preset #
01 – 64
X1)
= Room # (for room presets)
01 – 10 (Each can have up to 10 presets (
X1@
s) assigned.)
X1!
= Name
12 alphanumeric characters maximum for presets, inputs, and outputs
11 characters maximum for room names
X1@
= Room preset #
01 – 10
X1&
= Group # (for I/O grouping) 1 – 4 (0 = no group)
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
I/O Grouping (continued)
Read input grouping
E
I
}
X1&
1
X1&
2
X1&
3
...
X1&
n
]
Each
X1&
entry is the group
number assigned to an input
position, starting from input 1.
n
is the highest-numbered
input for this model.
Example:
MAV Plus 4848
E
I
}
See below.
01
Input:
Response = group:
Input 1 in group 1
02 03 04 05 06 07 08 09 10 11 12
1 1 1 3 3 0 0 0 0 4 4 4 4 1 1
13 14 15
Input 9 not grouped
1 2 2 3 3 3 3
35
34
36 37 38 39 40 41
2 1 2 2 3 3 3
42 43 44 45 46 47 48
Input 48 in group 3
Read output grouping
E
O
}
X1&
1
X1&
2
X1&
3
...
X1&
n
]
Each
X1&
entry is the group
number assigned to an output
position, starting from
output 1. n is the highest-
numbered output for this
model.
Names
Write global preset name
EX(,X1!
NG
}
Nmg
X(,X1!]
Example:
E
1,Security 1NG
}
Nmg01
,
Security 1
]
Name global preset 1
“Security 1”.
Read global preset name
EX(
NG
}
X1!]
Example:
E
2NG
}
Security 2
]
Global preset 2 is named
“Security 2”.
Write room name
EX1),X1!
NR
}
Nmr
X1),X1!]
Example:
E
1
,
Classrm 1NR
}
Nmr01
,
Classrm 1
]
Name room 1 “Classrm 1”.
Read room name
EX1)
NR
}
X1!]
Write room preset name
EX1)
*
X1@,X1!
NP
}
Nmp
X1)
*
X1@,X1!]
Example:
E
1*3
,
Podium_DVDNP
}
Nmp01*3
,
Podium_DVD
]
Name room1, preset 3
“Podium_DVD”.
Read room preset name
EX1),X1@
NP
}
X1!]
N
• If a preset is unassigned, the
X1!
displays
[unassigned].
• If a global preset is saved, but not yet named, the default name is Preset
X(
.
• If a room preset is saved, but not yet named, the default name is Rm
X1)
Prst
X1@
.
Write input name
EX$,X1!
NI
}
Nmi
X$,X1!]
Example:
E
1
,
Podium camNI
}
Nmi01
,
Podium cam
]
Name input 1 “Podium cam”.
Read input name
EX$
NI
}
X1&]
Write output name
EX@,X1!
NO
}
Nmo
X@,X1!]
Example:
E
1,Main PJ1NO
}
Nmo01,Main PJ1
]
Name output 1 “Main PJ1”.
Read output name
EX@
NO
}
X1!]
