PowerCage FOX SR HDMI Scaling Receiver • Introduction 1
Introduction
WARNING: Risk of eye injury: The PowerCage™ FOX SR HDMI outputs continuous
invisible light, which may be harmful to the eyes; use with caution.
• Do not look into the fiber optic cable connectors or into the fiber optic cables
themselves while the receiver is powered on.
• Plug the attached dust caps into the optical transceivers when the fiber cable is
unplugged.
This section introduces the Extron PowerCage FOX SR HDMI Scaling Receiver, including:
• About this Guide
• About the PowerCage FOX SR HDMI Receiver
• Features
About this Guide
This guide includes instructions for an experienced installer to install, configure, and operate
the ultra-high performance fiber optic receiver (see figure
1).
FOXBOX Tx HDMI
OPTICAL HDMI INPUT AUDIO INPUT
RS-232 OVER FIBER ALARM
Tx Rx 1 2
POWER 12V
1.0 A MAX LINK LINK
Rx Tx
PowerCage 1600 Power Supply
N15778 C US
LISTED
1T23 L.T.E.
5A MAX. 100-240V 50/60Hz
PowerCage 1600 Power Supply
1 2
REMOTE RS-232 RS-232 OVER FIBER
Tx
ALARM
Rx
OUTPUT
PowerCage FOX SR HDMI
Tx Rx G Tx Rx G
VIDEO HDCP
ON
HDMI
AUDIO OFF
AUDIO
AUDIO
R
L
Extron
PowerCage 1600
Flat Panel Display with Speakers
1080p HDMI
Extron
PowerCage FOX SR HDMI
Fiber Optic Scaling Receiver
Extron
FOXBOX Tx HDMI
Fiber Optic Transmitter
Laptop
1280 x 800
Figure 1. Typical PowerCage FOX SR HDMI Application
