PowerCage FOX SR HDMI Scaling Receiver • Remote Control 13
Remote Control
This section describes the remote control operation of the PowerCage FOX SR HDMI,
including:
• Serial Ports
• Simple Instruction Set Control
• Signal Processing Control Program Control
Serial Ports
The receiver board has an RS-232 serial port on three pins of a 5-pole captive screw
connector that can be connected to a host device (see
item g on page 6).
The PowerCage enclosure has a Configuration port, a 2.5 mm mini stereo jack, that
parallels the board ports (see
item e on page 12).
These serial ports make serial control of the transmitter and receiver possible, using devices
such as a computer running the Extron DataViewer or MicroSoft HyperTerminal utility or a
control system.
The protocol for all ports is as follows:
• 9600 baud • no parity • 8 data bits
• 1 stop bit • no flow control
NOTE: The Remote RS-232 port is active only if the PowerCage Configuration port is
not active. If an active Configuration port connection is made, the Remote RS-
232 port for that board becomes inactive.
Simple Instruction Set Control
Host-to-Unit Instructions
SIS commands consist of one or more characters per field. No special characters are
required to begin or end a command character sequence. When a command is valid, the
unit executes the command and sends a response to the host device. All responses from
the unit to the host end with a carriage return and a line feed (CR/LF = ]), which signals the
end of the response character string. A string is one or more characters.
