MTP R 15HD RSA D • Reference Information
20
Cables
N
Enhanced Skew-Free™ A/V UTP cables are not
recommended for Ethernet/LAN applications.
Enhanced Skew-Free™ A/V cable
Part number
Enhanced Skew-Free A/V cable
(cut, various lengths)
26-569-xx
Enhanced Skew-Free A/V 1000'
(Bulk) (non-plenum)
22-141-03
Plenum enhanced Skew-Free A/V 1000‚
(Bulk)
22-142-03
Connectors
Connector
Part number
CAT 6 jack (black), qty. 10
100-476-01
CAT 6 jack (red), qty. 10
100-477-01
CAT 6 jack (blue), qty. 10
100-478-01
CAT 6 jack (orange), qty. 10
100-479-01
CAT 6 jack (gray), qty. 10
100-480-01
CAT 6 jack (white), qty. 10
100-481-01
CAT 6 jack (ivory), qty. 10
100-482-01
