MTP R 15HD RSA D • Reference Information
Reference Information, cont’d
19
Part Numbers
MTP receiver and compatible transmitters and
switchers
N
A complete transmission system requires at
least one transmitter and one MTP receiver (the
MTP R 15HD RSA D, for this manual).
Receiver
Part number
MTP R 15HD RSA D receiver
60-929-01, 02
Compatible devices
Part number
MTP
T 15HD RS transmitter
60-652-01
MTP T 15HD A transmitter
60-669-01
MTPX Plus 816
60-834-01
MTPX Plus 168
60-833-01
MTPX Plus 1616
60-832-01
MTPX Plus 1632
60-898-01
MTPX Plus 3216
60-899-01
MTPX Plus 3232
60-897-01
MTPX 816
60-831-01
MTPX 168
60-830-01
MTPX 1616
60-829-01
MTPX 1632
60-895-01
MTPX 3216
60-896-01
MTPX 3232
60-894-01
