MS9400 HD FrEND User Guide Appendix D: Specifications
61 Rev. 1.54
Audio
ƒ Stereo analog audio output via L/R RCA phono line out connector.
ƒ Stereo Audio 100mV p-p
ƒ Front panel Volume control
Audio Processing
ƒ Dolby Digital AC3
ƒ Sampling Rates 44.1KHz, 48KHz
ƒ Audio Bit Rate 384Kbps
SPDIF
ƒ Output via RCA phono connector
ƒ Digital Audio IEC – 61937 (SPDIF)
ƒ Audio Output Level 1V p – p
ƒ Audio Output Impedance 600 ohms
Network
RJ45 Ethernet 10/100Base T auto sensing.
Physical Features
Chassis Weight 13 lbs.
Chassis Dimensions 2.01" (H) x 11.36" (W) x 12.37" (D)
51.1mm (H) x 288.4mm (W) x 314.2mm (D)
Power, Voltage 110/220 VAC 50/60 Hz Auto Ranging, 250 Watts
Environmental 10 to 40C Ambient, 90% RH non-condensing
Safety Compliance UL, CSA,
