MS9400 HD FrEND User Guide

Chapter 5: Playing Files

34 Rev.

1.54

Startup Playlist

The MS9400 control software is programmed to look for a “Startup” playlist. If one has been generated the
playlist will begin running automatically anytime the MS9400 is turned on.

To generate a Startup playlist

1. Using any text editor on your PC, open a new text file called startup.lst (All text in this file is case

sensitive).

2. Enter the sequence for each MPEG file to be contained in the list:

MediaPath (enter/return)

MediaFileName (enter/return)

InpointOutpoint (enter/return). Inpoint and Outpoint are set as ‘0’ and ‘-1’ respectively; if any
other settings are required consult Electrosonic.

As an example (using fictional video file names) the startup playlist could be written:

/media

panorama.mpg

0 -1

/media

tinaturns.mpg

0 -1

/media

sunspots.mpg

0 -1

3. Using your FTP application (refer to the previous chapter) up-load the Startup file (startup.lst) to the

/media folder on the MS9400

The Startup playlist will search for the files on the MS9400 and play them in the order defined in the list.

MS9400 in a larger system

Access the control features described above through a LAN system and a sequencing/scheduling application such
as ESCAN by Electrosonic Media Networks Division.

Refer to Chapter 6: Remote Control Protocol, for more information.

Refer to Chapter 7: Using the GPIO Control Interface.
