FOX II DP Transmitter and Receiver • Remote Control
18
Remote Control
This section describes the remote control operation of the FOX II DP transmitter and
receiver, including:
•
Simple Instruction Set Control
•
Product Configuration Software
The transmitter and receiver each have a front panel Configuration port, a mini USB jack
on page 12) and a rear panel Remote RS-232
port, a 3-pole captive screw connector (see
on page 12).
Any of these ports can be connected to a host device such as a computer running the
HyperTerminal or DataViewer utility, or a control system to make serial control of the
transmitter and receiver possible.
The protocol for all ports is as follows:
•
9600 baud
•
no parity
•
8 data bits
•
1 stop bit
•
no flow control
NOTE: RS-232 commands and Product Configuration Software functions are
transmitter- or receiver-specific or may have different responses depending on the
unit connected. You must connect to the appropriate device for the command or
function to work properly or to get the expected response.
Simple Instruction Set Control
Host-to-Unit Instructions
SIS commands consist of one or more characters per field. No special characters are
required to begin or end a command character sequence. When a command is valid, the
unit executes the command and sends a response to the host device. All responses from
the unit to the host end with a carriage return and a line feed (CR/LF = ]), which signals the
end of the response character string. A string is one or more characters.
