background image

Command

ASCII Command

(host to scaler)

Response

(scaler to host)

Additional Description

Overscan mode (applies only to SMPTE [NTSC, PAL, SECAM, 480p-1080p 50/60] input rates)

Set value

E

X#

*X2#OSCN}

OscnX#*X2#]

Set input format

X#

to overscan mode

X2#

.

View status

E

X#

OSCN}

X2#]

Show overscan mode status for input
format

X#

.

HDCP notification (green screen/message)

Enable notification

E

N1HDCP}

HdcpN1]

Enable the HDCP notification.

Disable notification

E

N0HDCP}

HdcpN0]

Disable the HDCP notification; instead
mute output.

Query notification

E

NHDCP}

X(]

Query the HDCP notification.

HDCP status (valid for HDMI input and HDMI ouput only)

Query input

E

IX!HDCP}

X2*]

HdcpIX!*X2*]

Query the HDCP status of the current
input

X!

.

(verbose mode response)

Query output

E

OX@HDCP}

X2*]

HdcpOX@*X2*]

Query the HDCP status of the HDMI
output

X@

.

(verbose mode response)

HDCP input authorization (valid for HDMI input only)

Enable HDCP
encryption support

E

EX!*1HDCP}

HdcpEX!*1]

Enable HDCP encryption support for
input

X!

(default).

Disable HDCP
encryption support

E

EX!*0HDCP}

HdcpEX!*0]

Disable HDCP encryption support for
input

X!

.

Query encryption
support status

E

EX!HDCP}

X4)]

Query HDCP encryption support status
for input

X!

.

NOTE:

X!

= Input selection:

1

to

3

X@

= Output selection:

1

= HDMI

X#

= Input video format:

1

= RGB

2

= YUV

3

= Composite

4

= HDMI

X(

= Enable or disable:

0

= Off or disable,

1

= On or enable

X2#

= Overscan (applied to SMPTE [NTSC, PAL, SECAM, 480p, 576p, 720p, 1080i, 1080p] input rates):

0

= 0.0% (default for RGB, HDMI) — a “true” Auto-Image will be executed on SMPTE inputs.

1

= 2.5% (default for YUV, composite) — an Auto-Image command snaps to a 2.5% table; no true Auto-Image.

2

= 5.0% — an Auto-Image command snaps to a 5.0% table; no true Auto-Image.

X2*

= HDCP status (valid only on TMDS inputs or outputs):

0

= No sink or source detected

1

= Sink or source detected with HDCP

2

= Sink or source detected but no HDCP is present

X4)

= HDMI input HDCP authorization status:

0

= Block HDCP encryption

1

= Allow HDCP encryption (default for input 3)

DSC 301 HD • SIS Communication and Control

34
