The viewable device status information is:

device internal temperature (in degrees F and C)

the current active input details (resolution, signal format, and total lines)

output resolution and refresh rate and output format

AFL status (locked or disabled)

HDCP status (input status and HDMI output status)

Display Info (resolution and refresh rate)

Firmware build details

Resolutions and Refresh Rates

In addition to the 83 factory rates, there are also three custom, user-defined or captured
rates available (C1 - C3). When no rate is captured or uploaded to any of the custom
slots, they revert to the default setting — 720p/60 Hz.

Resolution

23.98 Hz

24 Hz

25 Hz

29.97 Hz

30 Hz

50 Hz

59.94 Hz

60 Hz

75 Hz

Custom 1 through 3

For captured or uploaded EDID tables

640 x 480

X

X

X

800 x 600

X

X

X

852 x 480

X

X

X

1024 x 768

X

X

X

1024 x 852

X

X

X

1024 x 1024

X

X

X

1280 x 768

X

X

X

1280 x 800

X

X

X

1280 x 1024

X

X

X

1360 x 765

X

X

X

1360 x 768

X

X

X

1365 x 768

X

X

X

1366 x 768

X

X

X

1365 x 1024

X

X

X

1440 x 900

X

X

X

1400 x 1050

X

X

1600 x 900

X

X

1680 x 1050

X

X

1600 x 1200

X

X

1920 x 1200

X

X

480p

X

X

576p

X

720p

X

X

X

X

X

X

*

1080i

X

X

X

1080p

X

X

X

X

X

X

X

X

2048 x 1080

X

X

X

X

X

X

X

X

*

= default value

Figure 15.

Resolution and Refresh Rates

When a new custom rate is captured or uploaded, the On-screen Display (OSD)
dynamically updates with the new rate for that custom slot. For example, if a custom
480p EDID is uploaded to slot C1, the LCD would read “C1: 720x480”. These three
custom slots are shared between custom output resolutions (based on preferred timings 1
block) and custom EDID tables, which can be assigned to any input.

DSC 301 HD • Operation

18
