The DSC 301 HD OSD Menu System — Configuration and Adjustments

Scaler configuration and adjustments can be performed by using the On-screen Display
(OSD) menu or the Extron Simple Instruction Set (SIS) of commands (see the “

SIS

Communication and Control”

section).

The OSD menu can be seen on the connected display device.

OSD Menu Navigation Using Front Panel Controls

Menu button — Press the Menu button to activate or deactivate the main menu.
Enter button — Press the Enter button to move between the submenus of a selected
main menu item and to exit and accept the setting.
Adjust ({, [) knobs — In the menu configuration mode, rotate the Adjust horizontal
([) knob and Adjust vertical ({) knob to scroll through submenu options and to make
adjustment selections.

Menu Overview

The OSD menu has nine configuration submenus; two of which are read only information
menus. The table below shows the submenus and submenu items.

NOTE: “Input x” refers to the selected input; for example “Input 2”.

NOTE: The Device Info menu and the Communication menu are read-only and

gives current device status.

Using each of the submenus, the video and audio inputs and the HDMI output of the
DSC 301 HD can be configured. In addition, the user can save and recall the input
configuration as an User Preset. The Advanced submenu allows the user to choose a test
pattern to aid in the system setup, as well as set up a screen saver display when there
are no active input signals. The remote control port configuration can be viewed using the
read-only Communication submenu. Elements of the device status can be viewed using
the read-only Device Info submenu. See each submenu on the following pages for details.

OSD Menu

Submenu

Submenu Item

Quick Setup

Auto-Image

Input x
Format

Input 2

EDID

Input 3

EDID

Output

Resolution

Audio Mute

Test

Pattern

User Presets

Recall

Save

Clear

Picture Controls

Image Position

(H and V)

Image Size

(H and V)

Brightness

Contrast

Color

Tint

Detail

Input

Auto-Image

Input x

Input

Format

Input x

Film Mode

Pixel Start

(H and V)

Active

Pixels

(H and V)

Total Pixels

Phase

Input x

HDCP

Authorized

Input x

EDID

Output

Resolution

HDMI

Format

HDCP

Notification

Input AFL

Audio

Audio Mute

Input x

Audio

Format

Input x

Gain/

Attenuation

Advanced

Test Pattern

Screen

Saver

Screen Saver

Timeout

Input x

Auto-


Input x

Aspect

Ratio

Input x

Auto-

Memory

Overscan

Auto Switch

Factory

Reset

Communication

Remote Port

Device Info

(read only menu)

Temperature

Active Input

Details

Output

Details

AFL Status

HDCP

Status

Display

Information

Firmware

Build

Details
