Symbol Definitions

• = Space
]

= Carriage return with line feed

¦ or

}

= Carriage return with no line feed

E

or W

= Escape

14

= Superscripts indicate the error message displayed if the command is entered incorrectly or

with invalid parameters. See

“Error Response References”

on page 21.

X!

= Input selection, 1-3

X@

= Output selection, 1 = HDMI

X#

= Input video format:

1 = RGB

2 = YUV

3 = Composite

4 = HDMI

X$

= Horizontal or vertical start — 0 to 255 (default midpoint = 128)

X%

= Pixel phase — 0 to 63 (default = 31)

X^

= Total pixels — (±512 of the default value)

X&

= Active pixels — (±512 of the default value)

X*

= Active lines — (±256 of the default value)

X(

= Enable or disable; 0 = Off or disable, 1 = On or enable

X1)

= Input standard:

0 = No signal detected

3 = NTSC 4.43

1 = NTSC 3.85

4 = SECAM

2 = PAL

- = N/A (occurs when input is an active RBG, YUV [but not NTSC/PAL], or HDMI signal

X1!

= Internal temperature (in degrees Celsius)

X1@

= Horizontal and vertical frequencies (format is three-digit with single decimal and leading zeros

for example, 075.3

)

X1#

= Text label or preset name:

up to 16 characters

NOTE:

User and input presets saved without a name are saved with the default names
“User Preset xx” (for example, User Preset 12) or Input Preset xxx (for example
Input Preset 006).

X1$

= Picture adjustment — 0 to 127 (default 64

)

X1%

= Horizontal and vertical position, range depends on resolution

,

with leading “+” or “-”,

for example, “-1075”
X1^

= Horizontal and vertical size, range range depends on resolution

DSC 301 HD • SIS Communication and Control

22
