Command

ASCII Command

(host to scaler)

Response

(scaler to host)

Additional Description

Output Configuration

Output scaler rate

Set output rate

E

X1&

RATE}

RateX1&]

Select output resolution and refresh
rate.

View output rate

E

RATE}

X1&]

Show selected output rate.

HDMI output format

Set format

E

X3!

VTPO}

VtpoX3!]

Set output color space/format for the
HDMI output X3!.

View setting

E

VTPO}

X3!]

Show current HDMI format.

Power save mode

Power save off

E

0PSAV}

Psav0]

DSC runs in full power mode (default).

Power save on

E

1PSAV}

Psav1]

DSC enters low power mode. Can
only be exited using

E

0PSAV}

command or front panel button press.

View setting

E

PSAV}

X3^]

View power save status.

Screen saver mode (action that takes place when no signal is detected on the selected input)

Set mode

E

MX2%SSAV}

SsavM

X2%]

Sets the screen saver mode to

X2%

(default: 1 = black)

View mode

E

MSSAV}

X2%

]

View the current screen saver mode.

Set sync time out
duration

E

TX2!SSAV}

SsavT

X2!]

Sets sync time out duration to

X2!

seconds (default: 501 = never).

View sync time out
duration

E

TSSAV}

X2!]

View sync time out duration

X2!

.

View screen saver
status

E

SSSAV}

X3&]

View the screen saver status

X3&

.

NOTE:

X1&

= Scaler resolution or EDID emulation:

Examples: 1024x768/60, 720p/60, 1080p/60, 1920x1200/60. See

SIS command EDID table

on page 18 for full details.

X2!

= On-screen menu time-out: (default =

60

seconds), output sync time-out (default =

501

- never)

0

= OSD never displayed/output sync is instantly disabled with no active input,

1

to

500

, in 1 second increments,

501

= OSD never times out/output sync never times out

X2%

= Screen saver mode:

1

= Black screen (default),

2

= Blue screen with OSD text

X3!

= HDMI output format:

0

= Auto (default)

1

= DVI

2

= HDMI RGB “Full”

3

= HDMI RGB “Limited”

4

= HDMI 444 YUV “Full”

5

= HDMI 444 YUV “Limited”

6

= HDMI 422 YUV “Full”

7

= HDMI 422 YUV “Limited” See

command description

for full details.

X3^

= Power save mode:

0

= Full power mode (default),

1

= Low power state

X3&

= Screen saver status:

0

= Active input detected; timer not running,

1

= No active input; timer is running;

output sync still active,

2

= No active input; timer has expired; output sync disabled

DSC 301 HD • SIS Communication and Control

31
