Interpreting Model Numbers
The model number of the AQUAVAR appears on the shipping carton label and on the technical data
label affixed to the model. The information provided by the model number is shown below:
AV2 V 20 010 D
AV Series
Torque
C = Constant Torque
V = Variable Torque
Input Voltage
2S = 230 Vac, single-phase
20 = 230 Vac, three-phase
40 = 460 Vac, three-phase
50 = 575 Vac, three-phase
Horsepower Rating
For example, 010 = 1 HP
Enclosure
D = NEMA 12 / IP55, with keypad
N = NEMA 4 or NEMA 3R
Power and Current Ratings
Motor Power Input Maximum Load
Maximum Output Output Current (A)
Model
HP kW
Voltage Current (A) Voltage
200/380 230/460/ Number
(Vac) 200/380 230/460/ (Vac)
Vac 575 Vac
Vac 575 Vac
AV2V2S010D 1.0 0.7 — 8.9 4.8 4.2
AV2V2S020D 2.0 1.5 — 16.2 7.8 6.8
AV2V2S030D 3.0 2.2
Single-phase
— 23.1
0 to 230
11.0 9.6
AV2V2S050D 5.0 3.7
200 to 230
— 32.9 17.5 15.2
AV2V2S075D 7.5 5.5
±15%
— 47.5 25.3 22.0
AV2V2S100D 10.0 7.5 — 62.8 32.2 28.0
AV2V20010D 1.0 0.7 5.6 4.8 4.8 4.2
AV2V20020D 2.0 1.5 9.0 7.8 7.8 6.8
AV2V20030D 3.0 2.2
Three-phase
12.7 11.0
0 to 230
11.0 9.6
AV2V20050D 5.0 3.7
200 to 230
20.2 17.5 17.5 15.2
AV2V20075D 7.5 5.5
±15%
29.2 25.3 25.3 22.0
AV2V20100D 10.0 7.5 37.2 32.2 32.2 28.0
Technical Characteristics
