Page 13
12
Electrical Connections
Installation Procedures
FAILURE TO DISCONNECT AND LOCKOUT ELECTRICAL POWER AND WAIT
FIVE MINUTES FOR CAPACITOR DISCHARGE BEFORE SERVICING AQUAVAR
CONTROLLER CAN CAUSE SHOCK, BURNS, OR DEATH.
WARNING!
WARNING!
Installation and maintenance must only be performed by properly trained and
qualified personnel equipped with the proper tools.
Note
INSTALL AN ALL LEG DISCONNECT SWITCH NEAR THE MOTOR.
INSTALL, GROUND, AND WIRE ACCORDING TO LOCAL AND
NATIONAL ELECTRICAL CODE REQUIREMENTS.
DISCONNECT AND LOCKOUT ELECTRICAL POWER BEFORE
INSTALLING OR SERVICING.
MOTORS WITH AUTOMATIC THERMAL PROTECTION MAY OPEN THEIR
ELECTRICAL CIRCUIT WHEN A THERMAL OVERLOAD EXISTS. THIS CAN
CAUSE THE MOTOR TO START UNEXPECTEDLY AND WITHOUT WARNING.
ELECTRICAL SUPPLY MUST MATCH PUMP’S AND AQUAVAR CONTROLLER NAME
PLATE SPECIFICATIONS. INCORRECT VOLTAGE OR WIRING CAN CAUSE FIRE
DAMAGE, AND VOIDS WARRANTY.
WARNING
Hazardous voltage
can shock, burn or
cause death.
WARNING
Hazardous voltage
can shock, burn or
cause death.
Power Rating
Weight
HP
Pounds
Kilograms
25
52.0
23.6
30
52.0
23.6
40
60.0
27.2
50
107.0
48.6
60
107.0
48.6
75
107.0
48.6
