Installation Procedures
16
AQUAVAR Model
Watts Dissipated
AV2V2S010D
19
AV2V2S020D
20
AV2V2S030D
27
AV2V20010D
19
AV2V20020D
20
AV2V20030D
27
AV2V20050D
29
AV2V20070D
36
AV2V20100D
34
AV2V20150D
68
AV2V20200D
73
AV2V40010D
20
AV2V40020D
21
AV2V40030D
27
AV2V40050D
30
AV2V40070D
36
AV2V40100D
40
AV2V40150D
46
AV2V40200D
50
AV2V40250D
75
AV2V40300D
76
AV2V40400D
80
AV2V40500D
134
AV2V40600D
145
AV2V40750D
150
AV2V50010D
20
AV2V50020D
21
AV2V50030D
27
AV2V50050D
30
AV2V50070D
33
AV2V50100D
39
AV2V50150D
43
AV2V50200D
44
AV2V50250D
73
AV2V50300D
78
AV2V50400D
82
AV2V50500D
135
AV2V50600D
143
AV2V50750D
152
Electrical Connections continued
Table 3: Required Dissipation When Fins are External to the Enclosure
